HOWO TX 6×4 Tow Truck

Basic Parameters

• Drive Type: 6×4
• Wheelbase: 3200 + 1400mm to 3825 + 1350mm (varies by different models)
• Body Dimensions:
• Length: 6.985 meters – 7.615 meters
• Width: 2.496 meters – 2.55 meters
• Height: 3.53 meters – 3.95 meters
• Tare Weight: 8.8 tons – 12 tons
• Total Weight: 25 tons (consistent across all models)
• Towing Capacity: 36.87 tons – 40 tons

Power system

• Engine:
• Fossil fuel version: China Shurui MC11H.49-50 (490 horsepower), Weichai WP13NG540E60 (540 horsepower for LNG)
• Electric version: Battery from Ningde Time (118 kWh/400 kWh/601 kWh)
• Transmission:
  China Shurui HW19712 (12-speed manual)
  HW25712XSTCL (12-speed manual for LNG models)

Chassis and suspension

• Rear axle ratio: 3.7 – 4.77 (varies by different models)
• Tire specifications: 315/80R22.5 (not marked for some models)
• Front/rear wheelbase:
• Front wheelbase: 2020mm – 2041mm
• Rear wheelbase: 1830/1830mm or 1860/1860mm

Other configurations

• Maximum speed: 89 km/h – 102 km/h (electric version typically 89 km/h)
• Target market: Coal transportation, sand and gravel materials, logistics distribution, etc.
• Origin: Jinan, Shandong Province; Chengdu, Sichuan Province
• Note: Specific parameters may vary depending on the vehicle model (such as T7H, V7-X, TH7, etc.) and the power type (fuel/LNG/electric).
