The core parameters of the HOWO 6×4 dump truck produced by Sinotruk include a 371-horsepower engine, HW19712 transmission, a cargo box size of 5.6×2.4×1.5 meters, and 10 tires. The specific technical indicators are as follows:
1. Power System
- Engine: Model WD615.95E or WD615.97E (depending on the configuration), maximum output power 272kW (371 horsepower), displacement 9.726L, complies with Euro III/Euro II emission standards.
- Transmission: Adopted HW19712 manual transmission to enhance transmission efficiency and reliability.
2. Body and Load Capacity
- Overall Vehicle Dimensions: The vehicle length is approximately 13 meters, with dimensions of 5.6×2.4×1.5 meters (for export version).
- Load Capacity: The total vehicle mass ranges from 25 to 40 tons, with a rated load capacity of 12.64 to 35 tons. It is suitable for scenarios such as mining and sandstone transportation.
3. Chassis and Tires
- Drive Type: 6×4 dual drive, wheelbase 5475mm, equipped with AC16/HC16 dual-axle chassis to enhance load-bearing stability.
- Tire Configuration: 10 tires of 12.00R20 1200R22.5, suitable for various terrains.
4. Other Key Parameters
- Fuel Economy: Approximately 20 liters per 100 kilometers (for diesel).
- Emission Standards: Complies with National III/European III standards. It is only available for non-road use or for export in China.
- Notes: The actual configuration may vary depending on the export version or special customization. Please refer to the actual vehicle for details.
