HOWO 371TX 8X4 Dump Truck
HOWO 371TX 8X4 Dump Truck - 图片 2
HOWO 371TX 8X4 Dump Truck - 图片 3
HOWO 371TX 8X4 Dump Truck - 图片 4
HOWO 371TX 8X4 Dump Truck - 图片 5
HOWO 371TX 8X4 Dump Truck - 图片 6
HOWO 371TX 8X4 Dump Truck - 图片 7
HOWO 371TX 8X4 Dump Truck - 图片 8
HOWO 371TX 8X4 Dump Truck - 图片 9

HOWO 371TX 8X4 Dump Truck

This HOWO TX 8×4 dump truck is the ultimate engineering tool launched by China Heavy Industry, designed specifically for efficient transportation. Equipped with a powerful WD615.47 engine (371 horsepower) and HW19710 transmission, it offers powerful performance and can easily handle heavy loads. The luxury version of the cab is equipped with a right-side door observation window, providing a wider field of vision and a more comfortable ride. The entire vehicle is designed to be sturdy and durable, making it a reliable partner for urban construction waste removal, mining transportation, and other scenarios. It helps you increase revenue by hauling more and driving more!

分类： 标签： , , 品牌：

Basic Configuration

  • Drive Type:  8×4
  • Engine:  WD615.47 model, 371 horsepower (273 kW), Euro II emission standard
  • Transmission:  HW19710 (10 forward gears + 2 reverse gears)
  • Front Axle:  HF9 drum type, single axle load 9 tons
  • Rear Axle:  AC16 or HC16, speed ratio 5.45, single axle load 16 tons

Cargo Box and Dimensions

  • Internal dimensions of cargo box:  7.6 meters × 2.4 meters × 1.6 meters
  • Overall dimensions:  approximately 11.3 meters × 2.55 meters × 3.4 meters (slight variations depending on configuration)
  • Lifting System:  Front-lift type HIAB lifting system

Other Parameters

  • Tires:  12.00R20 18-ply radial steel tires, 12.00R22.5 18-ply radial tubeless tires
  • Fuel Tank Capacity:  300 liters
  • Cab:  HW76 with single bunk and air conditioning
  • Curb Weight:  approximately 12.6 tons – 15.45 tons (varies depending on configuration)
    Note:  Some parameters may vary depending on the vehicle model version or regional configuration.
尺寸 1130 × 255 × 340 厘米
